Product Description
Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUVs. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting and an attractive billet reservoir mount where applicable providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.Features & Benefits:
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Self-adjusting deflective disc valving reacts immediately to surface changes enabling maximum vehicle control
- Remote reservoir increases shock oil capacity for greater heat dissipation
Additional Attributes:
- GTIN: 00651860654584
- Adjustable Damping: Non-Adjustable
- Billet Reservoir Clamp Included: No
- Body Design: Smooth Body (Non-Coilover)
- Boot Included: No
- Collapsed Length (IN): 16.44
- Collapsed Length (MM): 417.5
- Extended Length (IN): 28.39
- Extended Length (MM): 721.0
- Finish: Zinc Plated
- Internal Design: Monotube
- Lower Mount Type: Bar Pin
- Optional Reservoir Clamp: 11-176015
- PartType: Shocks / Struts
- Piston Diameter: 46mm
- Reservoir: Yes
- Segment: Light Truck
- Series: B8 5160
- Shaft Diameter: 14mm
- Spring Seat Included: No
- Stroke/Travel Length (IN): 11.95
- Stroke/Travel Length (mm): 303.5
- Upper Mount Type: Stem
Extended Information:
- Emissions : Emissions Compliance Exempt
- Life Cycle Status: Discontinued
Packaging:
- Quantity of Each: 1.0
- Package UOM: EA
- Dimension: 26.8000 x 6.1000 x 6.1000 inches
