Product Description
Bilstein Motorsports dampers are designed as a direct fit solution for a variety of motorsports applications. Each damper features monotube technology with proprietary spring steel valve discs tuned specifically to each application for superior on-track handling and control. Bilstein Motorsports dampers are ideal for racers requiring a direct fit solution with true race-proven performance.Features & Benefits:
- Monotube design ensures consistent, fade-free performance in all conditions
- Larger working piston with deflective disc valving
- Available in steel and aluminum bodies
Additional Attributes:
- GTIN: 00790832526105
- Adjustable Damping: Non-Adjustable
- Body Design: Smooth Body (Non-Coilover)
- Body Material: Steel
- Boot Included: No
- Collapsed Length (IN): 12.77
- Collapsed Length (MM): 324.3
- Compression @0.52m/s: Custom
- Extended Length (IN): 20.09
- Extended Length (MM): 510.2
- Finish: Chrome Plated
- Internal Design: Monotube
- Lower Mount Type: Stem
- PartType: Strut Cartridge
- Piston Diameter: 36mm
- Piston Type: Linear
- Rebound @0.52m/s: Custom
- Segment: Motorsports
- Series: Motorsports
- Shaft Diameter: 11mm
- Spring Hardware: N/A
- Spring Seat Included: No
- Stroke/Travel Length (IN): 7.32
- Stroke/Travel Length (mm): 185.9
- Upper Mount Type: Stem
- Valving Identifier: Custom
Extended Information:
- Emissions : Emissions Compliance Exempt
- Life Cycle Status: Discontinued
Packaging:
- Quantity of Each: 1.0
- Package UOM: EA
- Dimension: 25.7500 x 2.2500 x 2.2500 inches
