Product Description
The ICON 3” Lift Rear Coil Spacer Kit is used as part of the ICON 6” Lift Performance Suspension System for the 2022-2024 Toyota Tundra and allows the OE rear coil springs to be reused to obtain the required rear lift at a lower cost while still allowing the option to upgrade to ICON Triple Rate Rear Coil Springs in the future. These high-quality spacers are fabricated from CNC laser cut steel and powder coated with a semi-gloss black finish.Features & Benefits:
- Allows use of OE rear coil springs with ICON 6” Lift Performance Suspension System
- Lower cost option compared to ICON Triple Rate Rear Coils
- Compatible with 2WD and 4WD models
- Fabricated steel construction
- Durable semi-gloss black powder coat finish
- ICON Limited Lifetime Warranty
Associated Comments:
- OEM Wheels & Tires Fitment: No
- Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.625” Backspace / 16mm Offset
- Recommended Aftermarket Tires: 37" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
- APPLICATION NOTE #85: Advertised Lift Height Ranges Are For A Stock Equipped Vehicle. Increasing Weight Of Vehicle Due To Accessories Will Alter Lift Range.
- APPLICATION NOTE #142: Not compatible with vehicles equipped with Load-Leveling Rear Height Control Air Suspension.
- APPLICATION NOTE #153: Not Compatible With Adaptive Variable Suspension (Avs) Equipped Vehicles
- APPLICATION NOTE #155: Requires recalibration of Advanced Driver Assistance Systems (ADAS) after install
- TECH NOTE: Requires additional components to complete system. DO NOT attempt install without part numbers 51010, 51011, 51012, 51014, and 51017.
Additional Attributes:
- GTIN: 00840103425542
- 10: Steel
- 17: Black
- 19: 3
- 9397: No
- AAP_UDA_12: EA
- AAP_UDA_22: 1
- AAP_UDA_4: 55
- California Prop 65 Warning: Yes
- Finish: Powder Coated
- Grade Type: Performance
- Universal Or Specific Fit: Specific
Extended Information:
- Emissions : 4
- Life Cycle Status: Available To Order
Packaging:
- Quantity of Each: 1.0
- Package UOM: EA
- Dimension: 19.0000 x 8.0000 x 9.0000 inches
I51016_REVA
