Product Description
ICON Vehicle Specific (V.S.) 2.0 Aluminum Series shock absorbers are the ultimate in cost effective upgrades, specifically tailored by ICON engineers for your application. The V.S. 2.0 Aluminum Series shocks are a high-quality upgrade for the everyday street driver and weekend warrior looking for improved on and off-road performance. Like all ICON shock absorbers, V.S. 2.0 Aluminum Series shocks are fully rebuildable and re-tunable. For those using their vehicle in extreme off-road situations, consider the ICON V.S. 2.5 Series shock to handle extra abuse and punishment your suspension will need to endure.Features & Benefits:
- Nitrogen charged monotube design with internal reservoir
- One piece linear/digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
- 5/8” chrome plated hardened steel shaft resists corrosion and pits
- 6061 aluminum rod end, top cap, and internals ensure strength and durability
- Polyurethane bushings, zinc plated sleeves, and forged steel mounting stems for OE factory type fitment
- 6063 anodized aluminum body and reservoir tubing for superb heat dissipation, excellent corrosion resistance, and high-tech appearance
- Nitrile rubber top out bumper for noise free operation
- Fully rebuildable and re-tunable
Associated Comments:
- APPLICATION NOTE #153: Not compatible with Adaptive Variable Suspension (AVS) equipped vehicles
- TECH NOTE: Compatible with 0-1.5” of rear lift on non-TRD Tundras or 0-1" lift on TRD Tundras equipped with rear coil springs
- TECH NOTE: Compatible with 0-3.5” of rear lift on Tundras equipped with rear OE Load-leveling Rear Height Control Air Suspension
- TECH NOTE: Compatible with 0-4” of rear lift on 2023-2024 Sequoias without TRD Off Road package or 0-2" of rear lift on 2023-2024 Sequoias equipped with TRD Off Road package and Sequoia TRD Pro.
Additional Attributes:
- GTIN: 00840103414348
- 10526: Digressive
- 10527: No
- 10528: No
- 10529: No
- 10530: Passive
- 10535: 3
- 11167: 0
- 1183: .625
- 1385: Gray
- 17: Black
- 200: Anodized
- 2329: Aluminum
- 30: No
- 3065: 2
- 3085: Single Tube
- 3390: Performance
- 408: Center of Eyelet
- 409: Shoulder of Stem
- 48: Eyelet
- 49: Stem
- 50: Yes
- 51: Yes
- 5126: Gray
- 52: 2
- 621: Aluminum
- 7233: No
- 8703: Yes
- 9388: Rubber
- 9444: No
- 9476: No
- 9621: No
- 9783: No
- 9792: No
- 9801: 1.75
- 9908: Yes
- AAP_UDA_12: EA
- AAP_UDA_22: 1
- AAP_UDA_4: 55
- Adjustable: No
- Adjustable Damping: No
- Bore Diameter: 1.75
- Bushing Color: Black
- Bushing Included: yes
- Bushing Material: Polyurethane
- California Prop 65 Warning: Yes
- Configuration: Performance
- Cylinder Finish: Anodized
- Damping Type: Oil
- Dust Boot Included: Yes
- Dust Shield: No
- External Reservoir: NO
- Material: Aluminum
- Quantity: 1
- Reservoir Type: Internal
- Service Parts: 202002 - 2.0 IFP REBUILD KIT
- Shaft Diameter: 0.625
- Shaft Material: Chrome
- Suspension Type: Air
Extended Information:
- Emissions : Emissions Compliance Exempt
- Life Cycle Status: Available To Order
Packaging:
- Quantity of Each: 1.0
- Package UOM: EA
- Dimension: 40.0000 x 3.0000 x 3.0000 inches
I56516_REVA
